Stanley DAP-3
All BEST Products

Best DAP-3-US26D Rescue Double Acting Pivot - Heavy Duty, Doors 1-3/8" to 1-3/4" Thick, US26D/626 Satin Chrome Finish

  • SKU: DAP3US26D
  • ✓
    In Stock
    In Stock
Your Price
$307.21 /ea

Best (Formerly Stanley) DAP-3-US26D Rescue Double Acting Pivot - Heavy Duty, Doors 1-3/8" to 1-3/4" Thick, US26D/626 Satin Chrome Finish

Features DAP-3 Stanley Hardware, Door Pivots, Hospital Door Hardware

  • Heavy-duty pivot assembly for commercial double acting interior doors of average frequency use, weighing up to 135 lbs. (61 Kg) and not exceeding 3' (91mm) in width
  • For 1- 3 /8" (35 mm) and 1- 3 /4" (44mm) thick doors
  • The header plate has a walking beam design to simplify door installation
  • Extra-heavy 1/4" (6.35mm) thick solid brass frame plates
  • Oil impregnated bronze bearing in top door plate
  • Smooth acting ball bearing assembly in bottom door plate
  • For door undercuts in 1/16" (1.6mm) increments from 3 /4" (19mm) to 1" (25mm)
  • A bottom bracket is frame-mounted and must be floor supported
  • The recommended positioning of the door is to inset it 1/8" (3.2 mm) from the bathroom face of the frame

Specifications For Best DAP-3 Rescue Door Pivot, Commercial Door Pivots, Double Acting Pivots

Header plate (brass): 4-7/8" x 7/8" x 1/4" (124mm x 22mm x 6.4mm)
Top door plate: 4-3/8" x 1" x 1/4" (111mm x 25.4mm x 6.4mm)
Bottom jamb bracket: 3" x 1-1/4" x 1/4" (76mm x 32mm x 6.4mm)
Bottom door plate: 4-3/8" x 1" x 1/4" (111mm x 25.4mm x 6.4mm)
Flat Head Screws Per Piece: Machine: 5 - 1 /4
