Commercial Door Closer Hole Pattern Guide

Looking to change or replace your current door closer?

Just measure the hole spacing of your current door closer, then locate a corresponding model from the provided chart below. This will ensure a smooth retrofit installation.

There are many factors to picking out the correct door closer for your use case. Amount of traffic, Interior or Exterior application, Handicap accessible delayed action, Hold Open features, and more. Give us a call at 800.992.3667 for further help finding the correct model. Virtual facetime appointments are also available for a more personal face to face support experience

9/16" Vertical Holes

9/16″ Vertical Holes x 11-1/8″ Horizontal Holes

Townsteel TDC-70

3/4" Vertical Holes

3/4" Vertical Holes x 12” Horizontal Holes

LCN 1450
Norton 8301, 8501
Yale 2701, 3301, 3501
Arrow 5016N
Sargent 1331

3/4" Vertical Holes x 10-1/4” Horizontal Holes

Best SL6014
Dorma 7414, 7436

3/4" Vertical Holes x 9-1/16” Horizontal Holes

LCN 1250, 1261
Norton 1601
Yale 51, 1101
Sargent 1131

1" Vertical Holes

1" Vertical Holes x 7-1/2” Horizontal Holes

LCN 1461

1" Vertical Holes x 4-5/16” Horizontal Holes

Corbin Russwin DC3210, DC6210

1" Vertical Holes x 11-1/8” Horizontal Holes

Sargent 1431

1" Vertical Holes x 10” Horizontal Holes

Corbin Russwin DC8210
Norton 9500

1" Vertical Holes x 10-3/8” Horizontal Holes

Sargent 281

1 3/8" Vertical Holes

1 3/8" Vertical Holes X 4 1/8” Horizontal Holes

Norton 78B-F
Yale 1900

1 23/32" Vertical Holes

1-23/32" Vertical Holes x 6-17/64” Horizontal Holes

LCN 4031

2 1/8" Vertical Holes

2 1/8" Vertical Holes x 5” Horizontal Holes

Dormakaba 8916

2 1/4" Vertical Holes

2 1/4" Vertical Holes x 5” Horizontal Holes

LCN 4040XP
Yale 5800
Norton 410
Hager 5100
Arrow DC500
Townsteel TDC-40

2 3/8" Vertical Holes

2 3/8" Vertical Holes x 6-3/4” Horizontal Holes

LCN 4050
Norton 7500
Yale 4400

2 1/2" Vertical Holes

2 1/2" Vertical Holes x 6" Horizontal Holes

LCN 4011, 4021, 4111

2 1/2" Vertical Holes x 9" Horizontal Holes

Sargent 351
