Available for fire door assemblies up to three hours (ferrous material) – specify F117-1/2. Intermediate pivot required by UL. Specify FM19 (order separately)
For 20-minute label suffix “–20” to the part number
Non-ferrous base material
Doors 60" (1524mm) to 90" (2286mm) in height should use one intermediate pivot. Each additional 30" (762mm) of door height warrants another intermediate pivot
3/4" (19mm) offset (measured from the centerline of pivot to face of door)
Available for 1-1/2" (38mm) offset (door weight 350 lbs.) for doors with cladding or frame molding
Door edges must be beveled 1/8" in 2"
Furnished with wood and machine screws
Extended spindles are available in 1/2" (13mm) increments up to 2" (51mm) longer than standard
