Rixson EH340-4W-626 Electrified Center Hung Top Pivot, 4 Wire, Satin Chrome Finish

The Rixson EH340-4W-626 is an electrified center hung top pivot engineered to transfer power discreetly through the top of a door while supporting reliable, controlled swing. Configured with a 4-wire setup, it enables the passage of electrical current to door-mounted electrified hardware such as electric locks, exit devices, or monitoring devices without exposing wiring. Finished in Satin Chrome (626), it delivers a clean, durable appearance suited to commercial openings. Designed to work with matching Rixson center hung floor closers and pivots, this top pivot provides dependable alignment and long-term performance in high-traffic institutional, commercial, and healthcare environments where concealed power transfer is required.

Features

• Electrified center hung top pivot for concealed power transfer through the door head.
• 4-wire configuration for supplying current to electrified door hardware.
• Satin Chrome (626) finish for a durable, corrosion-resistant appearance.
• Designed for use with compatible Rixson center hung floor closers and pivots.
• Center hung mounting supports balanced door swing in both directions.
• Suited for demanding commercial, institutional, and healthcare openings.

Functional Details

As a center hung top pivot, the EH340-4W carries the upper load of the door while providing an integrated electrical pathway. The four conductors run through the pivot to power electrified hardware mounted on the door, eliminating exposed cabling and maintaining a finished appearance.

Arm Type Details

This is a center hung pivot arrangement, meaning the door pivots on a vertical axis set inward from the door edge. The top pivot works together with a center hung floor closer or pivot at the bottom, allowing the door to swing in both directions while remaining properly aligned and supported at the head.
