Schlage ALX70P6-ATH Classroom Cylindrical Lock, Athens Lever, 6 Pin Schlage "C" Keyway, Keyed Different

  • SKU: ALX70P6ATH626
  • ✓
    In Stock
    In Stock
Your Price
$315.97 /ea
Finish: US26D-626 Satin Chrome

Schlage ALX70-P6-ATH Classroom Cylindrical Lock, Field Selectable Vandlgard, Athens Lever, 6 Pin Schlage C Keyway, Keyed Different, [2] Keys, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 2, Non-Handed

Schlage ALX70P6-ATH classroom cylindrical lock engineered for educational environments. Features the Athens lever design with 6-pin Schlage "C" keyway and field-selectable Vandlgard protection against tampering. Grade 2 rated for reliable security in high-traffic settings. Non-handed installation accommodates left or right door configurations. Includes 2 keys, 2-3/4 inch backset, and 4-7/8 inch strike plate. Keyed different for individual access control across multiple doors.

ALX70 Single Cylinder Deadbolt Function, Classroom lock

  • Key cylinder outside; plain lever inside; deadlatch
  • Key in outside lever locks or unlocks outside lever
  • Field selectable Vandlgard® feature
  • Inside lever always free for immediate egress
Manufacturer Schlage
Grade Grade 2
Installation Commercial
Origin Mexico
Unit of Measure Each
UL Listing Type UL/cUL
ANSI Number A156.2-2011 Series 4000, Grade 2
Limited Warranty 10 Years
Fire Rated 3 Hours {A}
ADA Compliance Yes



Function 70-Classroom Lock
Function Family Classroom
ANSI Function F84 - Classroom
Lever/Knob Design ATH Athens Lever
Lever/Knob Design Family Curved Lever
Rose/Escutcheon Design 3-7/16" Rose Diameter
Rose/Escutcheon Dimensions Rhodes
Cylinder Type Conventional Cylinder
Num Pins 6
Key(s) Cut
Num of Keys 2
Handing Non-handed
Door Thickness 1-3/8 In. - 1-3/4 In.
Std. Latch Number 47267042
Std. Latch Type Deadlatch
Std. Latch Backset Dim 2-3/4 In.
Latch Bore Diameter 7/8 In.
Lock Face Size 1-1/8 In. x 2-1/4 In.
Bolt Projection 1/2 In.
Bore Hole Diameter 2-1/8 In.
Std. Strike Number 47267101
Std. Strike Type ANSI Strike
Std. Strike Height 4-7/8 In.
Std. Strike Width 1-1/4 In.
Screws Combination
Product Type Cylindrical Lock
