Schlage ND80EU/EL LLL XXX LLL LLL Electrified Cylindrical Lock, Chassis Only, Storeroom Function

Technical Specs

Product Specs

Schlage ND80EU/EL LLL XXX LLL LLL Storeroom Lock Function, Grade 1, Electrified Cylindrical Lock, Chassis Only, Less Cylinder, 12-24VAC/DC, Fail Safe/Fail Secure

Schlage ND80EU/EL LLL XXX LLL LLL Electrified Cylindrical Lock is designed for use in storerooms and is equipped with a Grade 1 chassis. It operates on 12-24VAC/DC and can be set to be either fail safe or fail secure. The lock also comes without a cylinder, making it a versatile and customizable option for your security needs.

• Less levers, less finish, less strike plate, less cylinder, Chassis only

ND Series Electrified Lever Locks

Electrified Schlage cylindrical locks offer superior energy efficiency and flexibility in wired electrified applications.

The electrified ND is ideally used in:

• High-traffic areas, where line power ensures continuous operation
• New construction, where electrified door prep, hinges, and wiring can easily be incorporated into the building

Key Features
All mechanical features plus:

• Auto-detecting 12-24VDC input
• Selectable EL/EU operation
• Low 0.23 amp max current draw that allows multiple locks on a single power supply
• Low 0.010 amp holding current that eliminates "hot levers" in electrically locked applications
• Modular Request to Exit (RX) that can be added at any time
• Inventory friendly–one lock supports 12-24V, EL, or EU, with or without RX
• Six electrified functions for application flexibility
