Name: Von Duprin 9847NL-OP 3 26D 36" Concealed Vertical Rod Exit Bar, Wide Stile Pushpad, 80" to 100" Door Height, Nightlatch Function, US26D Satin Chrome
Brand: VON DUPRIN
SKU: 9847NLOP326D
Price: 2295.07 USD
Availability: InStock

All VON DUPRIN Products

Von Duprin 9847NL-OP 3 26D 36" Concealed Vertical Rod Exit Bar, Wide Stile Pushpad, 80" to 100" Door Height, Nightlatch Function, US26D Satin Chrome

SKU: BPBNTB622NR605

Von Duprin 9847NL-OP 3 26D Vertical Rod Exit Bar Nightlatch Function Satin

All VON DUPRIN Products

Von Duprin 9847NL-OP 3 26D 36" Concealed Vertical Rod Exit Bar, Wide Stile Pushpad, 80" to 100" Door Height, Nightlatch Function, US26D Satin Chrome

SKU: 9847NLOP326D

$2,295.07/ea

In Stock

In Stock

Quantity:

Qty

Description
Technical Specifications
Document Center

Description

Von Duprin 9847 NL-OP 3 26D Concealed Vertical Rod Exit Bar

The Von Duprin 9847 Series is for use on single or double metal doors, UL listed for panic exit hardware. Devices are ANSI A156.3 – 2008 Grade 1.

Device functions: Device ships EO/DT/NL. Field selectable. For TP, K or L remove the NL drive screw from the device.
Device lengths: 2' 2' (610 mm) Door size 3' 2'4' to 3' (711mm to 914 mm) Door size 4' 2'10" to 4' (864 mm to 1219 mm) Door size
Device centerline from finished floor: 395 /8" (1006 mm) Standard Adjustable from 355 /8" (905mm) to 495 /8" (1260mm) Center case dimensions 8" x 2 3/4" x2 3/8" (203mm x 70mm x 60mm)
Mechanism case dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
Projection: Pushbar neutral – 3 13/16" (97 mm) Pushbar depressed – 3 1/16" (78 mm)
Latch bolt: Deadlocking top & bottom bolt, 5 /8" (16mm) throw
Door undercut: 1 /4" (7mm) recommended
Top & bottom Latch case: 4 1/2" x 2 1/8" x 1 1/2" (114mm x 54mm x 38mm)
Vertical rods: Round 2-piece adjustable rods – Top rod adjustable from 6'8" (2027mm) to 8'4"(2533mm). Bottom rod adjustable 35 5/8" (905 mm) to 49 5/8" (1260 mm). Extension rod kits available for doors over 8'4" (2533mm).
Fasteners & sex bolts (SNB): Includes screw pack for 1 3/4" (44mm) to 2 1/4" (57mm) thick metal doors. Optional 425 SNB available.

Technical Specifications

Technical Specs
Physical Appearance	Wide Stile Pushpad
Device Type	Concealed Vertical Rod
Mechanical Function	Nightlatch
Device Length	36"
Hand	Field Reversible
Dogging Options	Hex Key Dogging
Top Strike	338
Strike Bottom	385A
Includes Trim	Yes
Trim Type	Cylinder Only
Trim Part No.	110MD-NL 26D
Includes Cylinder(s)	No
Cylinder Type	Rim
Minimum Stile Size	4-1/2"
Door Material	Hollow Metal
Door Width	28" to 36"
Door Height	80" to 100"
Door Thickness	1-3/4" - 2-1/4"
Fire Rated	No
Reversible	Yes
Product Type	Concealed Vertical Rod Exit Devices
