The Corbin Russwin CL3357-NZD-626-CL6 is a Cylindrical Lever Lockset in Classroom Function, that is Grade 1, has a CL6 6 Pin LFIC Core that is Sold Less Core, a Newport Lever, a 2 3/4 Backset, a 4 7/8 Strike, and comes in 626 Satin Chrome Finish.

Function: Storeroom or Closet

Deadlocking latch bolt by key in outside lever or by rotating inside lever (Lever handle is freewheeling in the locked position)
Inside lever is always free

Handing	Non-handed (Except FZD trim)
Door Thickness	1-3/4" (44mm) - 2" (51mm) standard. Optional: Over 2"(51mm) - 2-1/4" (57mm)
Lock Chassis	Steel, zinc dichromate for corrosion resistance.
Backset	2-3/4" (70mm) standard. Optional: 3-3/4" (95mm) and 5" (127mm)
Latchbolt	Stainless Steel, 1/2" (13mm) throw. Optional: 3/4" (19mm) throw deadlocking fire latch for pair of doors
Auxiliary Latchbolt	Deadlocking latch bolt prevents manipulation when the door is closed.
Front	Wrought brass, bronze, or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm). Accommodates flat doors and doors beveled 1/8" (3mm) in 2" (51mm). Optional: rounded corners
Strike	Wrought brass or stainless steel ANSI curved lip standard, 4-7/8" (124mm) x 1-1/4" (32mm) x 1-1/4" (32mm) lip to center. Optional strikes, lip lengths, and ANSI wrought strike box available
Cylinder	Brass, 6-pin L4 keyway, Std KR See Options
Keying Features Available	Master keying All Options Below Call For Pricing Construction master keying Visual key control Concealed key control Interchangeable core (IC) Security Security IC (not available with CL3329) Pyramid (not available with CL3329) Pyramid IC (not available with CL3329) Access 3® Access 3® IC (not available with CL3329)
Keys	Two nickel silver standards Except for Less Coire.
Warranty	Seven-year limited.

Product Specs

Manufacturer	Corbin Russwin
SKU	CL3357 NZD 626 CL6
Grade	Grade 1
Installation	Commercial
Origin	United States
Unit of Measure	Each
Base Material	Brass, Bronze
UL Listing Type	ANSI A156.2, Series 4000, Grade 1, UL Listed
ANSI Number	F86
Limited Warranty	7 Year Warranty
Fire Rated	3 Hours {A}
Burglar Rated	No
Finish	626/US26D
Finish Description	Satin Chrome
Finish Family	Matte Silver

Technical Specs

Function	57 Storeroom or Closet
Function Family	Storeroom
ANSI Function	F86 - Storeroom
Lever/Knob Design	NZ - Newport Lever
Lever/Knob Design Family	Straight Return Lever
Rose/Escutcheon Design	D Rose
Rose/Escutcheon Dimensions	3 1/2"
Cylinder Type	Corbin Russwin 6-Pin LFIC Less Core
Num Pins	6
Handing	Non-handed
Door Thickness	1 3/4" to 2"
Std. Latch Number	586F17
Std. Latch Type	Deadlatch
Std. Latch Backset Dim	2-3/4"
Latch Bore Diameter	1"
Lock Face Size	1 1/8" x 2 1/4"
Bolt Projection	1/2"
Bore Hole Diameter	2 1/8"
Std. Strike Number	SA114
Std. Strike Type	ANSI Curved Lip Strike
Std. Strike Height	4 7/8"
Std. Strike Width	1 1/4"
Screws	Wood/Machine Screws
Product Type	Cylindrical Lock
