Schlage CO-100 Series Standalone Electronic Locks

Introduction

Schlage CO‑100 Series standalone electronic locks are PIN‑code–driven locks that store user rights locally at the door and are programmed directly from the keypad. They are available in cylindrical, mortise, mortise deadbolt, and exit trim chassis, making them a versatile solution for schools, healthcare, offices, and multifamily facilities seeking reliable keypad access without complex wiring or software.

Key Features

• Keypad‑only credentials: Supports up to 500 unique 3‑ to 6‑digit PIN codes, stored on the lock for standalone operation.
• Multiple chassis options: Cylindrical, mortise, mortise deadbolt, and exit trim versions to match different door types and hardware standards.
• Manually programmable at the door by administrator‑level users using the keypad to add/delete PINs and change functions or preferences.
• Three factory‑configured functions (Classroom/Storeroom, Office, Privacy) available, plus credential attributes such as normal, toggle, pass‑through, and freeze.
• Battery powered with 4 AA batteries, offering up to 2 years of operation and visual/audible status via tri‑colored LEDs and beeper indicators.
• Outdoor‑rated options: Certain functions are fully outdoor rated for pool gates, breezeways, and other exterior applications.
• Grade 1 and security certifications: ANSI/BHMA Grade 1, ANSI/BHMA A156.25, UL 294, UL 10C, and hurricane/wind impact listings on appropriate models.

Key Benefits

• Reduces key management by shifting most day‑to‑day access to PIN codes, protecting the integrity of the master key system and simplifying re‑issuance when users change.
• Simple, cost‑effective electronic access: No network, control panels, or wiring to the door are required, making CO‑100 ideal for incremental upgrades or smaller facilities.
• Fast local programming enables staff to grant or revoke access quickly at the door without waiting for IT or locksmith support.
• Flexible user rights and functions allow tailoring each opening for classroom/storeroom, office, or privacy use, including visual occupancy indication on newer privacy models.
• Rugged, proven platform built on Schlage Grade 1 mechanical chassis, providing long‑term reliability in high‑traffic environments.

Applications

• K‑12 and higher education: Classroom, storeroom, and office doors where PIN codes replace or supplement mechanical keys while keeping free egress.
• Healthcare and commercial offices: Supply closets, nurse stations, offices, and exam rooms needing simple keypad access and occupancy indication.
• Fitness centers, multifamily, and hospitality: Workout rooms, pool gates, common areas, and resident‑only spaces using keypad entry instead of card readers.
• Retail and light industrial: Maintenance rooms, stock rooms, and restricted support areas where audit trails aren’t required but PIN control is desired.

Popular Schlage CO‑100 Series Standalone Electronic Locks

• Schlage Electronics CO100CY70 KP RHO 626 JDCO6 CO‑100 Standalone Classroom Electronic Cylindrical Lock: The CO100CY70 KP RHO 626 JDCO6 is a standalone classroom electronic cylindrical lock with keypad reader, Rhodes lever, and prep for large format interchangeable core in Satin Chrome. It uses keypad PIN codes for access and is well suited to classroom or office doors that require Grade 1 cylindrical strength with simple keypad control.
• Schlage Electronics CO100CY70‑KP‑RHO‑626‑J Classroom/Storeroom Electronic Cylindrical Keypad Lock, FSIC Prep: The CO100CY70‑KP‑RHO‑626‑J is a Grade 1 standalone cylindrical keypad lock with Classroom/Storeroom function, Rhodes lever, and full‑size interchangeable core (FSIC) prep, Satin Chrome. It stores up to 500 PIN users and is ideal for schools and commercial facilities that want keypad entry plus mechanical key override with FSIC convenience.
• Schlage Electronics CO100MS70 KP ATH 626 PD CO‑100 Standalone Classroom Electronic Mortise Lock: The CO100MS70 KP ATH 626 PD is a standalone classroom electronic mortise lock with keypad reader, Athens lever, and Schlage C key cylinder in Satin Chrome. It combines the strength and flexibility of a mortise chassis with keypad‑only electronic access, making it a strong choice for higher‑security interior or exterior doors needing robust hardware and simple PIN management.

 With a curated selection of Schlage CO‑100 standalone electronic locks in cylindrical and mortise configurations, competitive pricing, and fast shipping on in‑stock models, QualityDoor.com helps customers quickly match the right function, lever style, and key system to each opening. Expert technical support ensures that facilities can deploy Schlage CO‑100 keypad locks that simplify key management, upgrade security, and keep doors code‑compliant across education, healthcare, commercial office, and multifamily projects.
