McKinney T4B3386-6x5-US32D-QC8 Electrified Heavy Weight Full Mortise Hinge, Ball Bearing, 6 in x 5 in, Quick Connect 8 Wire, 630 Satin Stainless Steel

The McKinney T4B3386-6x5-US32D-QC8 is a heavy weight full mortise hinge engineered for high-traffic openings that demand reliable performance and electrified power transfer. Built with a five knuckle, ball bearing design, this hinge measures 6 inches by 5 inches and features Quick Connect 8-wire technology for fast, secure electrical connections between the frame and door. Finished in 630 satin stainless steel, it offers durability and corrosion resistance ideal for commercial and institutional environments. The electrified through-wire construction lets you power devices such as electric locks, exit devices, and monitoring hardware while maintaining the strength expected from a McKinney heavy weight hinge.

Features

• Heavy weight construction rated for high-frequency, high-traffic doors.
• Five knuckle, ball bearing design ensures smooth, long-lasting operation.
• Quick Connect 8-wire electrified transfer for powering door-mounted hardware.
• Satin stainless steel finish (630/US32D) resists corrosion and wear.
• Full mortise mounting for a clean, flush installation.
• 6 in x 5 in size suited to heavier commercial doors.

Functional Details

The electrified hinge carries current through concealed wiring in the barrel, transferring power from the frame to the door without exposed cabling. The Quick Connect system uses pre-terminated wire connectors to simplify installation and reduce wiring errors in the field.
