Sargent 12-8875-F-ETB-24V Electrified Fire Rated Rim Exit Device, Fail Safe Power Off Unlocks Lever, Key Retracts Latch, For 33-36 Inch Width Door, Less Dogging — Core Options: KD LA keyway keyed differently with 2 change keys; or LC Less Cylinder (Option)

The Sargent 12-8875-F-ETB-24V is a fire rated rim exit device built for demanding commercial openings that require reliable life-safety performance and electrified access control. Part of Sargent's 80 Series, this unit pairs a rim-mounted latch with electrified ETB lever trim operating on 24 volts. Configured for fail safe operation, the trim unlocks when power is removed, making it well suited for applications where free egress and controlled re-entry are essential during a power loss. Designed for doors measuring 33 to 36 inches in width, it comes less dogging as required for fire rated installations and delivers the durability expected from Sargent hardware.

Features

• Fire rated rim exit device suitable for use on labeled fire doors.
• Electrified ETB lever trim provides controlled access from the outside.
• Operates on 24V DC for integration with access control systems.
• Fail safe design unlocks the outside lever when power is removed.
• Key retracts the latch for mechanical override and entry.
• Sized for door widths from 33 to 36 inches.
• Furnished less dogging to meet fire rating requirements.
• Optional: KD LA keyway keyed differently with 2 change keys.
• Optional: LC Less Cylinder.

Functional Details

This device operates as a fail safe electrified unit, meaning the outside lever trim is locked when energized and unlocks automatically when power is interrupted, allowing controlled entry while maintaining free egress at all times.

• Fail Safe: Power off unlocks the lever.
• Key retracts latch.
• Outside trim is continuously locked until electrically released.

Arm Type Details

The ETB designation refers to Sargent's electrified B lever trim, which provides a keyed lever on the exterior that controls access electronically while the interior push bar always permits free egress.

Included Components

The device ships as a complete rim exit assembly with the electrified ETB lever trim, 24V wiring provisions, and mounting hardware for the specified door width.
