Sargent LC-12-56-8876-J-ETL-12V Electrified Fire Rated Rim Exit Device, Fail Secure Power Off Locks Lever, Key Retracts Latch, Electric Latch Retraction, For 37-42" Width Door, Less Cylinder, Less Dogging

The Sargent LC-12-56-8876-J-ETL-12V is a heavy-duty electrified rim exit device built for fire-rated openings that demand reliable access control. Operating in fail-secure mode, the device keeps the outside lever locked when power is removed, while electric latch retraction allows remote release and momentary unlocking through an access control system. Engineered for doors measuring 37" to 42" wide, it ships less cylinder and less dogging to suit fire-rated applications where mechanical dogging is not permitted. With the ETL (electric latch retraction) option and 12-volt operation, this Grade 1 device delivers dependable security and smooth egress in high-traffic commercial environments.

Features

• Electrified fire-rated rim exit device for life-safety and access-controlled openings.
• Fail-secure operation keeps the outside lever locked when power is removed.
• Electric latch retraction (ETL) retracts the latch remotely for momentary or timed access.
• Sized for door widths from 37" to 42" for broad fit coverage.
• Supplied less cylinder, allowing you to match existing keying systems.
• Less dogging, as required for fire-rated door assemblies.
• 12-volt operation for integration with low-voltage access control.
• J-style lever trim for comfortable, code-compliant operation.

Functional Details

In the 56-8876 fail-secure configuration, the exit device keeps the lever locked on the exterior side during a power loss, maintaining security on the opening. Electric latch retraction pulls the latchbolt back electronically, enabling push/pull operation or remote release while the latch stays retracted. Free egress from the inside is always available by pressing the push bar.

• Fail secure: power off locks lever.
• Key retracts latch.
• Electric latch retraction for remote momentary unlocking.

Arm Type Details

This is a rim-mounted exit device, with the latching mechanism and push bar installed on the surface of the door's interior face. The latch engages a surface-mounted strike on the frame, making it one of the simplest configurations to install and service on single or paired fire-rated openings.

Included Components

The device includes the 8876 rim exit chassis with J-style electrified lever trim and the integrated electric latch retraction assembly. A cylinder is not included and must be ordered separately to complete keyed exterior access.
