The Schlage ND10S Cylindrical Passage Set with the Boardwalk (BRK) lever delivers Grade 1 performance for demanding commercial openings where locking is not required. This non-keyed passage function allows the door to latch freely from both sides, making it ideal for corridors, closets, and other high-traffic pass-through areas. Equipped with an integrated Request-to-Exit (RX) switch, this set supports electronic access control and monitoring by signaling authorized egress. Built on Schlage's heavy-duty ND platform, it features a 2-3/4 inch backset, a 4-7/8 inch strike, and a non-handed design that simplifies installation and inventory. Durable construction ensures reliable, long-term operation in institutional and commercial environments.
Features
Functional Details
The ND10S passage function keeps the latch operable at all times, allowing free entry and exit without a locking mechanism. The RX switch monitors lever movement to send a signal to connected access control or alarm systems, indicating a legitimate exit request.
| Manufacturer | Schlage |
| SKU | ND10S-BRK-RX |
| Function | Passage, Non-Keyed with Request-to-Exit Switch |
| Lever Style | Boardwalk (BRK) |
| Grade | ANSI/BHMA Grade 1 |
| Handing | Non-Handed |
| Origin | Made in the USA |
| Unit of Measure | Each |
| ANSI Number | A156.2, Series 4000 |
| BAA Qualified | Yes |
| Limited Warranty | Three-Year Limited Warranty |
| Backset | 2-3/4 Inch |
| Strike Size | 4-7/8 Inch |
| Latch Type | Cylindrical |
| Latch Face | 1-1/8 Inch x 2-1/4 Inch |
| Door Thickness Range | 1-3/8 Inch to 2 Inch (standard) |
| Bolt Type | Deadlatch |
| Chassis | Cylindrical, Heavy-Duty |
| Lever Rotation | Both Sides Always Free |
| Switch Type | Request-to-Exit (RX) |
| ANSI Operational Grade | Grade 1 |
| Cross-Bore Diameter | 2-1/8 Inch |
