The Schlage ND10S-LAT-RX is a Grade 1 cylindrical passage set built for the demands of high-traffic commercial openings. Featuring the modern Latitude lever and a factory-installed Request to Exit (RX) switch, this non-keyed lockset lets both levers operate freely at all times while providing an electrical signal to access control or monitoring systems when the door is used. Part of Schlage's heavy-duty ND Series, it comes non-handed for simple installation on any door and ships with a 2-3/4 inch backset and 4-7/8 inch strike. It's an ideal choice for corridors, restrooms, and interior doors that need reliable, code-compliant hardware with integrated monitoring capability.
Features
Functional Details
As a passage function (ND10S), the latch is retracted by turning either the inside or outside lever, and there is no locking mechanism. The integrated RX switch monitors lever movement, sending a signal to connected security or building systems whenever the door is operated.
| Manufacturer | Schlage |
| SKU | ND10S-LAT-RX |
| Series | ND Series |
| Function | Passage / Closet (Non-Keyed) |
| Lever Style | Latitude |
| Grade | ANSI/BHMA Grade 1 |
| Handing | Non-Handed |
| Origin | Made in USA |
| Unit of Measure | Each |
| UL Listing Type | UL Listed for 3-Hour Fire Doors |
| ANSI Number | A156.2 |
| BAA Qualified | Yes |
| Limited Warranty | Manufacturer Limited Warranty |
| Backset | 2-3/4 inches |
| Strike | 4-7/8 inches |
| Latch Bolt Throw | 1/2 inch |
| Door Thickness Range | 1-3/8 inches to 2 inches (standard) |
| Chassis Type | Cylindrical |
| Function Number | ND10S |
| ANSI Function | F75 |
| Switch Type | Request to Exit (RX) |
| Lever Trim | LAT (Latitude) |
| Bore Diameter | 2-1/8 inches |
| Cross Bore | 1 inch |
