The Schlage ND10S-TLR-RX is a Grade 1 cylindrical passage set built for high-traffic commercial openings where reliable access and electronic monitoring are both required. This non-keyed passage function allows the latch to retract freely from either the interior or exterior lever, making it ideal for corridors, restrooms, and general-use doors that don't need locking. The integrated Request-to-Exit (RX) switch signals building security or access control systems when the lever is operated, supporting egress monitoring and alarm coordination. Featuring the durable tubular lever design (TLR), a 2-3/4 inch backset, and a 4-7/8 inch strike, this non-handed set installs on standard door prep for dependable, long-term performance.
Features
Functional Details
The ND10S passage function keeps the latchbolt operable by the lever from either side at all times, with no cylinder or locking mechanism. The RX switch monitors lever movement and reports egress activity to connected systems.
| Manufacturer | Schlage |
|---|---|
| SKU | ND10S-TLR-RX |
| Series | ND Series |
| Function | Passage (Non-Keyed) |
| Grade | Grade 1 |
| Lever Style | Tubular Lever (TLR) |
| Handing | Non-Handed |
| Origin | Made in USA |
| Unit of Measure | Each |
| ANSI Number | A156.2 |
| BAA Qualified | Yes |
| Limited Warranty | Three-Year Limited Warranty |
| ANSI/BHMA Standard | ANSI/BHMA A156.2, Series 4000, Grade 1 |
|---|---|
| Backset | 2-3/4 inches |
| Strike Size | 4-7/8 inches |
| Latch Type | Cylindrical |
| Door Thickness Range | 1-3/8 inches to 2 inches (standard) |
| Latchbolt Throw | 1/2 inch |
| Chassis Material | Steel |
| Special Feature | Request-to-Exit (RX) Switch |
| Cross Bore | 2-1/8 inches |
| Latch Bore | 1 inch |
