Schlage ND70PD-RHO Classroom Cylindrical Lock, Rhodes Lever, Keyed Different

  • SKU: ND70PDRHO626

Schlage ND70PD-RHO Classroom Cylindrical Lock, Rhodes Lever, Keyed Different

  • SKU: ND70PDRHO626
Sale price$514.96/ea
In Stock
In Stock
Keyway: Schlage "C" Keyway
Schlage Finish: -626 - Satin Chromium Plated
Visa Mastercard American Express Discover Shop Pay Apple Pay

The Schlage ND70PD-RHO is a Cylindrical Classroom Lock, with a Rhodes Lever, is available in Schlage C Keyway or S123 Keyway, is Keyed Different, comes with 2 Keys, has a 2-3/4" Backset, a 4-7/8" Strike, is Grade 1 and comes in multiple finishes.

Classroom Function - Outside lever locked and unlocked by key. Inside lever always unlocked.
Schlage ND70 Function Chart

ND Mechanical Overview

The Schlage ND is extremely versatile and is regularly used in healthcare, education, government, office, retail and other commercial applications. With 31 mechanical functions, the ND's range spans from the simple (non-locking passage) to complex (double-cylinder security) to specialized (school time-out lock). Because the ND uses an ANSI 161 door prep, commonly used across cylindrical locks, it is ideal for both new construction and retrofit applications.

  • Significantly exceeds ANSI/BHMA A156.2 requirements for Grade 1 cylindrical locks
  • 31 mechanical functions
  • Nine lever designs, two rose designs
  • 10 available finishes
  • Supports standard, SFIC and FSIC cylinder formats
  • Multiple key systems available – open, patented, restricted, geographic exclusive, UL437
  • Support for 10 non-Schlage cores
Manufacturer Schlage
SKU ND70PD RHO
Grade Grade 1
Installation Commercial
Origin Mexico
Unit of Measure Each
UL Listing Type UL/cUL Listed
ANSI Number ANSI A156.2 Series 4000, Grade 1
BAA Qualified Yes
Limited Warranty 10 Years
Fire Rated 3 Hours {A}
ADA Compliance Yes
Function 70 Classroom Lock
Function Family Classroom
ANSI Function F84 - Classroom
Lever/Knob Design RHO Rhodes Lever
Lever/Knob Design Family Straight Return Lever
Rose/Escutcheon Design 3-7/16" Rose Diameter
Rose/Escutcheon Dimensions 3-7/16"
Cylinder Type Cylinder
Num Pins 6
Key(s) Cut
Num of Keys 2
Handing Non-handed
Door Thickness 1-5/8 In. to 2-1/8 In.
Std. Latch Number 13-247
Std. Latch Type Deadlatch
Std. Latch Backset Dim 2-3/4 In.
Latch Bore Diameter 1 In.
Lock Face Size 1-1/8 In. x 2-1/4 In.
Bolt Projection 1/2 In.
Bore Hole Diameter 2-1/8 In.
Std. Strike Number 10-025
Std. Strike Type ANSI Strike
Std. Strike Height 4-7/8 In.
Std. Strike Width 1-1/4 In.
Screws Wood/Machine Screws
Product Type Cylindrical Lock
