What Are Sargent PE80 Series Exit Devices?

The Sargent PE80 Series Exit Devices are engineered to meet the rigorous demands of environments where a robust exit solution is necessary. These top-notch devices are specifically designed for high-usage areas like schools, hospitals, commercial buildings, and public spaces, easily overcoming challenges.

With various configurations, including rim, mortise panics, surface vertical rod, and concealed vertical rod options, the PE80 Series meets and exceeds ANSI/BHMA Grade 1 standards. This means you can expect nothing less than premier performance and unwavering reliability regarding your safety requirements.

Features of Sargent PE80 Series Exit Devices

The following are some of the top features of this series:

  • Better Security: The PE80 series exceeds the ANSI/BHMA Grade 1 standards, providing unmatched security and making it perfect for areas that require high levels of protection.
  • Ease of Use: Designed for effortless operation, these devices ensure quick and safe egress during emergencies. The expansive stile pushpad design provides a greater surface area for easy actuation.
  • Aesthetic Compatibility: With a sleek satin stainless steel finish, these devices enhance contemporary architectural styles and maintain their appearance, even under strenuous use.  The 281 door closer cover was made to match the PE80 Series look and design.
  • Cost Efficiency: Exceptional durability reduces the necessity for frequent replacements, offering savings on maintenance costs over time.
  • Innovative Features: Engineered with cutting-edge enhancements for superior security and functionality, these devices offer a modern aesthetic and an enhanced user experience. The Center Case Adjustability feature eliminates the challenges and time to adjust latch engagement on vertical rod devices. The design has a flush profile to eliminate catch points.
  • Strong Construction: These devices, made of sturdy materials, are tailored to endure the demands of high-traffic settings and promise long-term reliability and consistent operation.
  • Flexible Configurations: These devices can accommodate a variety of door types and security requirements, with options including rim PE8800, PE8300 narrow stile, 8900 wire stile mortise exit devices, PE8700 Series surface vertical rod, PE8600 Wide stile, and PE8400 Series narrow stile concealed vertical rod exit devices, which are offered in many different functions.
  • Status Indicators: The PE80 Series includes three status indicator options to provide occupants with peace of mind and security.
  •  The Active Dogging Indicator is displayed on the rail for visual confirmation if the door is dogged down.
  • Our 18-Passive Dogging option has a subtle display on the side of the push bar.
  • The 49-Trim Status Indicator option has a large display on the chassis cover for our Classroom Intruder Functions.
  • Ratings and Certifications: Hurricane-rated, Windstorm-rated, UL Listings,  Florida building codes FL2998, FEMA Publication 361 (2021), ICC500 (2020), and Tornado-rated.

Electrified Options

  • 53- Latchbolt monitoring switch (not available with 59- option),
  • W53- Weather Resistant Latchbolt monitoring with (not available with 56-, 58-, 59- & AL)
  •  54- Monitors ET lever movement with Internal micro switch in ET control W54- Weather Resistant Lever monitoring with (not available with 56-, 58-, 59- & AL)
  •  55- Request to exit - signal switch in rail (not available with 59-option)
  • W55- Weather Resistant Request to exit - signal switch in rail (not available with 56-, 58-, 59- & AL)
  • 55-ERM- Double touch bar monitoring W55-ERM Weather Resistant double touchpad monitoring with (not available with 56-, 58-, 59- & AL)
  • 56- Remote latch retraction (not available 58-, 59-, AL, W53- W54- & W55-)
  • 58- Electric rail dogging (not available 56-, 59-, W53-, W54- and W55- options) 59- Electroguard® self-contained delayed egress device (not available with 16-, 53-, W53-, W54, 55-, W55-, 56-, 58-, AL- &, GL- options )
  • AL- Alarmed exit (not available 16-, 56-, 59-, W53, W54, and W55- options) HK- Electrified exit device with manual hex key dogging (available with 56-, 58- option)
  • WH- Weep Holes (not available with 56-, 58-, 59- & AL) WR- Wire harness included when electrified trim is ordered separately (supplied standard with 59-)

Mechanical Options:

Certifications 12- UL fire label exit hardware (not available with 16-, 18-& HK- options)

HC- Hurricane-rated WS- Windstorm rated Cylinder

LC- Less cylinder Dogging 16- Cylinder lockdown with # 41 cylinder (not available with 12-, 59-, AL-, HK- options)

LD- Less dogging for non-fire-rated devices Door Type 31- Doors over 1-3/4" and panels (specify door thickness, panel thickness & location as required) End Cap

OL- Overlap end cap Fasteners 36- Six lobe security head screws TB- Thrubolts Finish Protection

CPC- Clear powder coat (available for 32 & 32D finishes) SG- MicroShield® antimicrobial clear powder coat (only available with 15, 26D, and 32D finishes - available as unique only)

Indicators 18- Passive dogging indicator

49- Trim Status Indicator (available on PE8816 and PE8866 functions only) Latching

GL- Guarded Latch Luminescence PL- SARGuide® photoluminescent push rail – (not available with 85 & 87 options) Rail Force 5CH- 5lb. Pressure Release Tactile Warning

76- Tactile warning - milled outside lever (not available with Studio Collection levers and the A lever)

85- Tactile warning - abrasive strip on push rail (not available with PL- option) 86- Tactile warning - abrasive coating on outside lever

87- Tactile warning - abrasive strip on push rail & abrasive coating on outside lever (not available with PL- option) Weather Resistant

WH- Weep Holes

Explore the Best Selling Sargent PE80 Series at Qualitydoor

Qualitydoor.com provides an extensive selection of door hardware products and accessories, ready to ship, from leading manufacturers like Sargent. Whether you need an exit device for a bustling public area or a secure private establishment, we can help you find the perfect solution.
