Lock Chassis Steel, and zinc dichromate for corrosion resistance.
Front Wrought brass, bronze, or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm) standard. Accommodates flat doors and doors beveled 1/8" (3mm) in 2" (51mm). Optional fronts available
Latchbolt Brass or stainless steel, 1/2" (13mm) throw.
Auxiliary Latchbolt Deadlocking latch bolt prevents manipulation when the door is closed.
Strike Wrought brass, bronze, or stainless steel ANSI curved lip standard, 4-7/8" (124mm) x 1-1/4" (32mm) x 1-1/4" (32mm) lip to center. Optional strikes, lip lengths, and ANSI wrought strike box available; see How to Order, page 9.
